Lining - The thin walled polyurethane lining is a single-ply extruded tube and is unaffected by ozone. The finished form is free of pits or other imperfections and has a smooth finish. No reclaimed material is used. The tensile strength of the liner is not less than 2000 psi, with a maximum elongation of 10 percent.
Couplings – Expansion-type hardcoat anodized aluminum meeting U.S. Forestry specifications are standard. NST, NPSH, or Quarter-Turn couplings are available.
Warranty - ATI warranties both the hose and couplings to be free from defects in material and workmanship for a period of 1 year. Upon evaluation, apart from mistreatment that would make it unfit for service, hose found to be defective will be repaired or replaced by ATI at no charge to the fire department.
Specifications:
| Size | Service Test | Proof Test | Burst Test | Weight (lbs.) |
| 1" | 300 psi | 600 psi | 900 psi | 4 |
| 1-1/2" | 300 psi | 600 psi | 900 psi | 7 |
Features:
- Meets or exceeds NFPA 1961 Fire Hose Standard, 2013 edition as well as U.S. Forest Service F-187 standard.
- Colors: white
- Available in the sizes of 1" and 1-1/2"
- The jacket is virgin high tenacity polyester
- Thin walled polyurethane lining is a single-ply extruded tube
- Unaffected by ozone.
- 1 Year Warranty
